The 10 Ton hydraulic swing arm clicker press delivers professional-grade cutting power with exceptional stability. Its advanced hydraulic system provides uniform 10-ton rated pressure, ensuring clean, burr-free cuts across various medium-thickness materials. The precision pressure adjustment valve allows seamless adaptation to leather, foam, rubber, and fabric, minimizing material waste and enhancing production quality. Constructed with an integral high-strength steel frame, this machine operates without vibration during long-term use, significantly extending service life and reducing maintenance costs.
Humanized Swing Arm Design: Efficient Operation
At the heart of its efficiency lies the 360° rotatable swing arm structure, enabling flexible switching between working positions. This design accelerates material loading and unloading, cutting operational time by up to 30% compared to traditional cutting equipment. The optimized angle provides clear operating vision, while the lightweight construction reduces worker fatigue. Ideal for small to medium batch production workshops, this swing arm clicker press maximizes workspace utilization without compromising on performance.
The technical parameters of swing arm clicker press
| Model | DSADM-10 | DSADM-12 | DSADM-16 | DSADM-20 |
| Max. Cutting Force | 100 KN | 120 KN | 160 KN | 200 KN |
| Max scissoning force | 0.10 m/s | 0.098 m/s | 0.10 m/s | 0.10 m/s |
| Seissor speed | 5-75 mm | 5-60 mm | 5-75 mm | 5-75 mm |
| Stroke adjustment | 60-120 mm | 60-120 mm | 65-150 mm | 65-150mm |
| Distance between upper table and lower able | 400*800 mm | 400*900 mm | 450*900 mm | 500*1000 mm |
| Overall dimension | 850*700*1250 mm | 900*800*1300 mm | 900*900*1380 mm | 1000*900*1380 mm |
| Motor power | 0.75 KW | 1.1 KW | 1.1 KW | 1.5 KW |
Safety & Durability: Reliable Use Guarantee
Safety and durability are paramount in this swing arm clicker press. Equipped with dual-hand operation buttons and an emergency stop device, it complies with CE international safety standards, protecting operators during production. High-quality hydraulic components and wear-resistant cutting die bases reduce frequent replacements, lowering long-term operational costs. Its compact structure saves floor space, making it perfect for factories with limited space.
Wide Application Scenarios: Multi-Industry Adaptability
Versatility defines the 10 Ton Hydraulic swing arm clicker press, serving multiple industries with exceptional results:
- Footwear industry: Precision cutting of upper leather, sole materials, and insole padding
- Bag processing industry: Clean cuts of cloth, artificial leather, and nylon materials
- Flooring & packaging industry: Processing of foam mats, rubber gaskets, and non-woven fabrics
- Automotive interior industry: Shaping of seat leather, sound insulation cotton, and component parts
Cost-Effective Solution: Global Customer Choice
For small to medium manufacturers worldwide, the 10 Ton hydraulic swing arm clicker press offers exceptional value. Its high cost-performance ratio outperforms larger cutting equipment, meeting strict budget requirements without sacrificing quality. The simple maintenance process—only regular hydraulic oil replacement and component inspections are needed—further reduces operational costs. Customizable configurations, including special cutting dies and pressure displays, allow tailoring to specific material processing needs of global customers.
Why Choose Our 10-Ton Swing Arm Clicker Press?
In summary, this machine combines precision, efficiency, and durability in one affordable package. Whether you’re in footwear, bag making, automotive interiors, or packaging, this swing arm clicker press delivers consistent results that drive business growth. Backed by CE certification and global support, it’s the ideal cutting solution for manufacturers aiming to enhance productivity and product quality.
